Insider leaks Intel 800 series chipset specifications
, by Quentin
A new leak has revealed the full details of Intel's upcoming 800 series chipsets. The consumer models are the Z890, B860 and H810, while there's also a workstation model, the W880, and a corporate desktop model, the Q870. There will be no H870 in this new series.
Z890 Chipset:
- PCIe 5.0 x16 slot for graphics card
- Up to 25 USB ports (shared though, not simultaneous)
- Overclocking support for CPU and bus
- Thunderbolt 4 / USB4 support
W880 Chipset:
- Identical to Z890 in terms of slots and ports
- Full ECC support, Intel vPro, and remote management
- No CPU and bus overclocking
Q870 Chipset:
- Reduced PCIe 4.0 lanes by four
- Reduced USB 3.2 ports (20 Gbps or 10 Gbps)
- Intel vPro and remote management support
- No overclocking features at all
B860 Chipset:
- Fewer PCIe lanes (10 fewer from chipset, four fewer from CPU)
- Reduced DMI interface lanes by four
- No bifurcation and PCIe RAID
- Limited to two 20 Gbps or four 10 Gbps USB 3.2 ports
- Memory overclocking supported
H810 Chipset:
- Basic configuration with 16 PCIe 5.0 lanes for graphics card
- Eight PCIe 4.0 lanes
- No 20 Gbps USB ports, just two 10 Gbps USB 3.2 ports
